One Station Disc, Small FS1DS


When you need to get the job done right and on time, you need professional-grade Metal Disc Benders by Malco, featuring removable discs for quick disassembly and mid-panel tool removal.

Why choose a 1-station model? These tools are best for short bends and curves!

Form 90°-180° bends to create hems and other details in any panel length on the jobsite, without waiting on wholesale roll formers. Metal Disc Benders by Malco are designed to form bends in a wide variety of materials for finishing custom straight or curved metal roofing details such as open hems for facia details, ridge caps and other interlocking features. HVAC pros can also use Malco’s Disc Benders for field-forming ductwork and creating open hems to prepare for drives.

Malco’s 1-Station Metal Disc Benders are available in two models:
Large 1-Station Disc (FS1DL): Makes 5/16″ – 1 3/4″ (8 – 45 mm) bends
– Small 1-Station Disc (FS1DS): Makes 5/16″ – 1 1/8″ (8 – 30 mm) bends

Three sets of bearing guides glide smoothly along material to follow the initial bend. Pair with the removable Disc Handle (FSH1) to make cross breaks in material, create designs and start bends on flat panels.

HVAC pros may also wish to pair the Disc Benders with a 1-Station or 2-Station Metal Bender to field-form rope hems and closed hems on the jobsite.

Malco’s Metal Disc Benders are built tough with premium CNC aluminum and stainless-steel components for more durability and stability, allowing for more precise and higher quality bends.

Features

  • Capacity of materials: 24 ga steel, 26 ga stainless steel, .040″ aluminum, 20 oz copper, 1 mm zinc
  • Small 1-Station Disc (FS1DS): Makes 5/16″ – 1 1/8″ (8 – 30 mm) curved or straight bends
  • Bend radius of .059″ (1.5mm
  • Pair with removable Disc Handle (FSH1) to make cross breaks in material, create designs and start bends on flat panels
  • Removable handle allows for compact storage
  • Quick setup, lightweight and highly portable
  • Premium CNC aluminum and stainless-steel components are built tough, resist corrosion and make the product more stable for precise bends

Specifications

Catalog Number Description Bending Capacity: Steel Bending Capacity: Stainless Steel Bending Capacity: Aluminum Bending Capacity: Copper Bending Capacity: Zinc Bend Depth Bend Range Bend Radius
FS1DS 1 Station Disc, Small 24-Gauge 26-Gauge  .040 20 oz 1 mm 5/16 in – 1 1/8 in (8mm – 30 mm) 90-180 degrees 0.059″ (1.5mm)
FSH1 Metal Bender, Handle, Disc
FSBAG Metal Bender, Bag
